Infineon FS820R08A6P2B: A High-Performance 820A Automotive Grade Power Module
The rapid evolution of automotive electrification demands power electronics that deliver not only exceptional performance but also uncompromising reliability. Addressing this critical need, the Infineon FS820R08A6P2B stands out as a premier automotive-grade power module engineered to set new benchmarks in electric vehicle (EV) powertrain systems.
This power module is built upon a robust 62mm housing platform, integrating a sophisticated six-pack IGBT configuration. Its most striking feature is its impressive 820A current rating at 80°C, coupled with a voltage rating of 750V. This high current density is paramount for managing the substantial power requirements of main traction inverters, which convert DC battery power to AC for driving the vehicle's electric motor. The module's low VCE(sat) and switching losses ensure high efficiency, which directly translates to extended driving range and reduced thermal management demands.
Beyond raw performance, the FS820R08A6P2B is designed for the harsh realities of the automotive environment. It boasts AEC-Q101 qualification and adheres to the stringent AQG-324 automotive standard, guaranteeing resilience against extreme temperatures, mechanical stress, and vibrational forces encountered in daily driving. The module utilizes advanced EDT2 IGBT technology and emitter-controlled diode concept, which optimizes switching behavior and minimizes electromagnetic interference (EMI)—a critical factor for vehicle electromagnetic compatibility (EMC).
Furthermore, its low-inductance design and the option for sintered or standard chip attachment enhance its power cycling capability and long-term reliability. The baseplate is optimized for low thermal resistance, enabling efficient heat dissipation into the cooling system and ensuring stable operation under peak load conditions.
ICGOODFIND: The Infineon FS820R08A6P2B is a cornerstone technology for next-generation electric vehicles, offering a potent combination of ultra-high power density, superior efficiency, and automotive-grade robustness. It empowers engineers to design more compact, powerful, and reliable traction inverters, accelerating the global transition to sustainable mobility.
Keywords: Automotive Grade Power Module, High Current Density, Traction Inverter, EDT2 IGBT Technology, AEC-Q101 Qualified.
